Directional Speaker | SSHA 6060

Targeted Audio. Exceptional Clarity. Zero Disturbance.

Panphonics directional speakers designed to deliver high-quality sound to a precisely defined area without bleeding into the surrounding environment.

Leveraging proprietary Plane Wave Technology, the Sound Shower creates a ” focused confined audio zone” that maintains extreme clarity and intelligibility, making it the premier choice for museums, retail spaces, banks, and digital signage.

Superior Speech Intelligibility

Optimized for the Superior Speech Intelligibility, Sound Shower ensures that spoken messages are crisp and clear, even in acoustically challenging environments with high ceilings or heavy echoes.

Smart Ambient Volume Control

Equipped with an integrated monitoring system, the speaker automatically adjusts its volume based on surrounding noise levels. This ensures your message is always audible during peak hours without being too loud during quiet periods.

Ultra-Thin & Discreet Design

With a profile of only 2-3cm, these speakers integrate seamlessly into any architectural environment. The lightweight aluminum frame and changeable cover canvas (available in custom colors and prints) make it as aesthetically pleasing as it is functional.

Ideal Applications

  • Museums & Galleries: Narrate specific exhibits without sound overlapping.

  • Retail & Banks: Target shoppers at specific displays or provide private audio at kiosks.

  • Privacy Solutions: Mask private conversations in banks or medical waiting areas.

  • Digital Signage: Increase “stopping power” by adding focused audio to visual displays.

  • Directional | Focused Audio Beam discreetly delivered
  • Electrostatic Technology
  • Active Speaker with built in amp
  • Capture Attention
  • Increase Privacy
  • 2 Ch RCA Audio Input
  • Simple to Install

Check Out Gear

Applications

Tech Specifications

octava hdmi video over ip audio

Audio Input

RCA Audio Input
Input Impedance, RCA: 10 KOhm
Input Voltage, RCA: 0.9 Vp-p

octava hdmi video over ip audio

Audio Output

Rated Output : 160 Vrms (135 nF load)
S/N Ratio: > 70dB
THD : <0.05 @ 75% Rated Output
Output Frequency min: 250 Hz-16 kHz

octava audio icon

Audio Footprint

4.2 x 4x2 ft (1.3 m x 1.3 m)

HDMI video over ip power

Powering

External Power Supply 24VDC, 2.5 A

Dimensions and colors

2 Sizes available:
Model SSHA6060 :60 x 60 cm
Model SSHA12020 :120 x 20 cm
Available colors: white, black

Operational Conditions

Temperature Range 0°C - 40°C (32°F - 72°F)
IP Class IP20
