Directional Speaker | SSHA 6060

Panphonics directional speakers can focus speech even in noisy environments without increasing the overall ambient noise level. In a museum setting, you can create a confined audio zone in front of an art piece where the desired sound is heard. When you step out of the zone, the volume will decrease drastically. To further combat the issue of overpowering ambient noise, we have optimized our speakers to play frequencies most sensitive to the human ear.

Applying the electrostatic principle, we have been able to create speakers with lower coloration, better transient response and lower distortion in comparison to other techniques.

Clear, focused sound field that remains audible even over longer distances.

The finished product is easy to install, has a light and unobtrusive design, and can withstand extensive use.

Ideal for  Museum and Galleries,  House of Worship,  Corporate spaces, Retail showrooms

  • Directional | Focused Audio Beam discreetly delivered
  • Electrostatic Technology
  • Active Speaker with built in amp
  • Capture Attention
  • Increase Privacy
  • 2 Ch RCA Audio Input
  • Simple to Install

Check Out Gear


Tech Specifications

octava hdmi video over ip audio

Audio Input

RCA Audio Input
Input Impedance, RCA: 10 KOhm
Input Voltage, RCA: 0.9 Vp-p

octava hdmi video over ip audio

Audio Output

Rated Output : 160 Vrms (135 nF load)
S/N Ratio: > 70dB
THD : <0.05 @ 75% Rated Output
Output Frequency min: 250 Hz-16 kHz

octava audio icon

Audio Footprint

4.2 x 4x2 ft (1.3 m x 1.3 m)

HDMI video over ip power


External Power Supply 24VDC, 2.5 A


23.7 x 23.7 x 2.15 Inches ( 60 x 60 x 5.5 cm) Length x Width x Height
Weight: 5.5 lbs ( 3.4 KG)

Operational Conditions

Temperature Range 0°C - 40°C (32°F - 72°F)
IP Class IP20

Request System Quote

Let us know about  your system. We will happily provide quotation  for review. There is no-obligations for purchase.
